FL Series Fluidized Granulator
Features:
The flow ability is improved and the dust is reduced, because of Granulator.
Its solubility is improved, because of Granulator, because of Granulator,
Mixing, Granulator and drying processes are completed in one step inside the machine.
The operation is safe because the anti-static filter cloth adopted.
It's safe for operator if explosion take place, because explosion device is adopted.
No need corner. Therefore the loading and unloading are quick, light and clean, meet the requirements of GMP.
Applications:
Pharmaceutical industry :tablet capsule, low sugar or no sugar granule of Chinese traditional medicine.
Foodstuff:cocoa,coffee,milk powder,juice of granulate,flavoring and so on.
Other industries:pesticide,feed,chemical fertilizer,pigment,dyestuff and so on.
Drying: powder or granule state of wet material
Coating: protection layer, color, controlled release, film, or bowels solved coating of granules and pills.
Principle:
The powder granule in vessel (fluid bed) appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.
Technical paramenters:
| item | unit | type | |||||||||
| 3 | 5 | 15 | 30 | 60 | 120 | 200 | 300 | 500 | |||
| vessel | volume | L | 12 | 22 | 45 | 100 | 220 | 420 | 670 | 1000 | 1500 |
| diameter | MM | 300 | 400 | 550 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | |
| capability | min | KG | 1.5 | 4 | 10 | 15 | 30 | 80 | 100 | 150 | 250 |
| max | KG | 4.5 | 6 | 20 | 45 | 90 | 160 | 300 | 450 | 750 | |
| fan | velocity | m3/H | 1000 | 1200 | 1400 | 1800 | 3000 | 4500 | 6000 | 7000 | 8000 |
| pressure | MM H2O | 375 | 375 | 480 | 480 | 950 | 950 | 950 | 950 | 950 | |
| power | KW | 3 | 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | 30 | 45 | |
| steam consumption | KG/H | 15 | 23 | 42 | 70 | 141 | 211 | 282 | 366 | 451 | |
| compressed air expenditure | m3/min | 0.9 | 0.9 | 0.9 | 0.9 | 1.0 | 1.0 | 1.1 | 1.5 | 1.5 | |
| weight of the main body | KG | 500 | 700 | 900 | 1000 | 1100 | 1500 | 1500 | 1800 | 2000 | |
| steam pressure | MPA | 0.3-0.6 | |||||||||
| temperature | ℃ | adjustable at the range from room temperature to 120℃ | |||||||||
| working time | MIN | decided in accordance with the properties of raw materials | |||||||||
| collect rate | % | ≥99 | |||||||||
| noise | DB(A) | when do installation ,main machine is separated from fan. | |||||||||
| size(L×W×H) | M | 1.0×0.6 ×2.1 | 1.2×0.7 ×2.3 | 1.25×0.9 ×2.5 | 1.6×1.1 ×2.5 | 1.85×1.4 ×3 | 2.2×1.65 ×3.3 | 2.34×1.7 ×3.8 | 2.8×2.0 ×4.0 | 3×2.25 ×4.4 | |
Detailed picture
